Thông số sản phẩm
- Hệ thống mạng tốc độ cao
- Khả năng truyền tải dữ liệu thông minh
- Sử dụng nguồn năng lượng hiệu quả
Thông số kỹ thuật
Size
11-inch Desktop/Rackmount Size, 1U Height
Number of Ports
24 10/100/1000 Mbps (Ports 1 to 12 are PoE enabled)
Port Functions
IEEE 802.3 compliant
IEEE 802.3u compliant
IEEE 802.3ab compliance
IEEE 802.3az compliant
Support manual/ auto MDI/ MDIX configuration
Auto-negotiation
Support Half/Full-Duplex operation
IEEE 802.3az compliant
Per-port 6 kV surge protection2
Auto-negotiation
Switching Capacity
48 Gbps
Maximum Forwarding Rate
35.71 Mpps
MAC Address Table Size
8K Entries
Packet Buffer
512 Kbits
Flash Memory
8 Mbyte
PoE
PoE Standard
802.3af/ 802.3at
PoE Capable Ports
Port 1 to 12
PoE Power Budget
100 W
LEDs
Power (per device)
Yes
Link/ Activity/ Speed (per port)
Yes
Power Input
100 to 240 VAC 50 to 60 Hz External Power Adapter
Power Consumption
128.32 watts (PoE on)
MTBF
563,292 hours
Ventilation
1 Fan
EMI
FCC Class A, CE Class A, VCCI Class A, C-Tick, BSMI, CCC
Safety
cUL, CE LVD, CB, BSMI, CCC
Dimensions
280 x 230 x 44 mm
Weight
2.15 kg
